Winding Resistance Tester HYZC-40A

There are four DC currents to select for HYZC-40A which has a large output power,and the power of the tester itself is very little. it is a ideal tester for testing various resistances especially the sensibility equipment.

Technical Specification

1. Resistance precision:±(0.2%RGD+2d)

2. Test range:

   4.000mΩ-4.000Ω  (5A)

   2.000mΩ-2.000Ω  (10A)

   1.000mΩ-1.000Ω  (20A)

   0.500 mΩ-0.500Ω (40A)

3. The least scale:1uΩ

4. Output current precision : ±5%

5. Support for data uploading to PC

6. Two hundred groups of data can be stored

7. With thermal printer to print the test data

8. Weight : 15KG

9. Power supply:AC220V±10%,(50±1)HZ

10. Operation condition:-10~50℃  humidity <90% no condensation
