Circuit Breaker Vacuum Degree Tester HYKZ-Ⅳ
Circuit Breaker Vacuum Degree Tester HYKZ-Ⅳ is the latest generation of products of our company. It has some features: higher measurement accuracy, better stability, more capacity. This instrument is a kind of practical testing instrument, which is widely used in the departments of electricity, steel, petrochemical, textile, coal, railway and so on.
Datasheet
Video
Contact Us1. HYKZ-IV vacuum tester uses the new excitation coil magnetron discharge method to test the vacuum of the arc extinguishing chamber without disassembling the arc extinguishing chamber.
2. It also used computer for synchronous control, data acquisition and processing, and the sensitivity of HYKZ-IV vacuum tester in the field test of the vacuum interrupter arc chamber is 10-5Pa.
3. The most outstanding feature of this instrument is the use of new excitation coils and data processing methods to achieve the non-demolition measurement of vacuum.
| Detection objects | various models of vacuum switch |
| Detection method | using new excitation coil and detect vacuum tube without disassembly |
| Application area | this instrument is a all-purpose type, can measure the vacuum of variety models of open magnetic vacuum tube |
| Detection range | 10-5-10-1 Pa |
| Measurement accuracy | 10-5-10-4 Pa, 10% |
| 10-4-10-3 Pa, 10% | |
| 10-3-10-2 Pa, 10% | |
| 10-2-10-1 Pa, 10% | |
| Magnetic field voltage | 1700V |
| High-voltage of pulsed electric field | 30KV |
| Open distance of switch tube in vacuum test | normal open distance |
| Testing environment | -20℃~ 40℃ |
| Weight | 12kg |
| Dimension | 420 × 320 × 280 (mm) |
| Sampler | magnetic coil |
-
